Lub tshuab coil slitting yog cov cuab yeej siv siv tau siv los txiav cov hlau coils ntev mus rau qhov dav uas yuav tsum tau ua thiab rov ua rau lawv mus rau hauv yob. Nws tuaj yeem tuav cov ntaub ntawv xws li stainless hlau, tooj liab, carbon hlau, hlau, galvanized, txhuas, thiab lwm yam.

Lub luag haujlwm tseem ceeb:

Slitting:Txiav dav stainless hlau coils rau hauv nqaim strips rau ntau yam kev xav tau.

Automated ntau lawm:Xws li uncoiling, leveling, slitting, thiab rewinding rau kev ua haujlwm zoo, tsis tu ncua.

High-precision txiav:CNC-tswj kom raug thiab sib xws txiav.
Versatility:Ua haujlwm nrog ntau yam hlau xws li stainless hlau, carbon hlau, silicon steel, thiab tinplate.

Technical parameters:

Specification	THK (mm)	Dav (mm)	ID (mm)	OD (mm)	Qhov hnyav (T)	Qhov tseeb (mm)	Ceev (m / min)	Peev xwm (KW)
1.0X360	0.1-1.0	100-360	Φ250/300	Tsawg dua los yog sib npaug rau Φ1200	Tsawg dua lossis sib npaug li 2.5	Tsawg dua lossis sib npaug rau ±0.05	Tsawg dua los yog sib npaug li 60	Tsawg dua los yog sib npaug li 45
1.2X500	0.15-1.2	100-500	Φ300/500	Tsawg dua los yog sib npaug rau Φ1200	Tsawg dua los yog sib npaug 3	Tsawg dua lossis sib npaug rau ±0.05	Tsawg dua los yog sib npaug li 120	Tsawg dua los yog sib npaug li 80
2.0X650	0.2-2.0	150-650	Φ508/610	Tsawg dua los yog sib npaug rau Φ1500	Tsawg dua los yog sib npaug li 6	Tsawg dua lossis sib npaug rau ±0.05	Tsawg dua los yog sib npaug li 180	Tsawg dua los yog sib npaug li 96
2.0X1000	0.2-2.0	300-1000	Φ508/610	Tsawg dua los yog sib npaug rau Φ1500	Tsawg dua los yog sib npaug li 15	Tsawg dua lossis sib npaug rau ±0.05	Tsawg dua los yog sib npaug li 180	Tsawg dua los yog sib npaug li 120
2.0X1600	0.2-2.0	500-1600	Φ508/610	Tsawg dua los yog sib npaug rau Φ1500	Tsawg dua los yog sib npaug li 20	Tsawg dua lossis sib npaug rau ±0.05	Tsawg dua los yog sib npaug li 200	Tsawg dua lossis sib npaug li 240
3.0X650	0.2-2.0	200-650	Φ508/610	Tsawg dua los yog sib npaug rau Φ1500	Tsawg dua los yog sib npaug li 15	Tsawg dua lossis sib npaug rau ±0.05	Tsawg dua los yog sib npaug li 150	Tsawg dua los yog sib npaug li 180
3.0X1250	0.3-2.75	500-1250	Φ508/610	Tsawg dua los yog sib npaug rau Φ1500	Tsawg dua los yog sib npaug li 15	Tsawg dua lossis sib npaug rau ±0.05	Tsawg dua los yog sib npaug li 180	Tsawg dua lossis sib npaug li 205
3.0X1600	0.4-3.0	600-1600	Φ508/610	Tsawg dua los yog sib npaug rau Φ1500	Tsawg dua los yog sib npaug li 25	Tsawg dua lossis sib npaug rau ±0.05	Tsawg dua los yog sib npaug li 120	Tsawg dua lossis sib npaug li 230
